How to gracefully delete a pod in Istio Service Mesh

Istio service mesh makes use of Envoy proxy as a pod sidecar to intercept all the traffic going to the application. This provides Istio users with capabilities such as traffic management, security policies enforcement and observability. At deletion time, it is needed to take some measures to have the best possible termination process.

When deleting a Pod, the kubelet sends a TERM signal to each container in the pod, specifically to PID 1, allowing each container to have some time to gracefully finishing its processes. If this gracefully termination exceeds the time defined in terminationGracePeriodSeconds , which is 30 seconds by default, the kubelet gives 2 extra seconds and sends the KILL signal, abruptly finishing PID 1 .

At deletion time, a problem will arise if your sidecar is not properly configured and synchronized with your app container. As the sidecar is the gateway for all outbound and inbound traffic to your application, if it is killed before your application has responded all its ongoing requests, you’ll probably get 5xx responses and an increased latency for those requests due to retries. With Istio and Kubernetes you have handy tools to avoid this scenario. It is a matter of harmonize the scenario.

Understand your specific use case

First of all, get to know your needs. Your application has specific response times and draining process. Make sure you have this numbers clear and config your lifecycle hook preStop accordingly.

We will assume here your app is a database which takes a maximum of 40 seconds to respond to its longest request. So your preStop should look like this:

        lifecycle:
          preStop:
            exec:
              command: ["sleep", "40"]

Kubernetes default is not enough

As terminationGracePeriodSeconds is by default 30 seconds, a pod as our database requiring maximum 40 seconds to complete a request will give us problems. You should set you deployment .spec.template.spec.terminationGracePeriodSeconds to 40. Remember the kubelet gives you 2 extra seconds on top of this time.

Envoy should hold the breath

Moving the kubelet patience to 40 seconds won’t do it. We also need to prevent the sidecar from dying during those 40 seconds, but also to avoid receiving new requests and allowing pending outbound ones.

Istio has a config for this exact behavior called terminationDrainDuration which is:

The amount of time allowed for connections to complete on proxy shutdown. On receiving SIGTERM or SIGINT, istio-agent tells the active Envoy to start draining, preventing any new connections and allowing existing connections to complete. It then sleeps for the termination_drain_duration and then kills any remaining active Envoy processes. If not set, a default of 5s will be applied. Source: Istio docs

It can be set at the meshConfig level, which is the configmap in istio-system namespace that defines settings for your service mesh as a whole, or defined at the pod level using an annotation.

Annotation way:

  template:
    metadata:
      annotations:
        proxy.istio.io/config: |
          terminationDrainDuration: 40s

Or meshConfig way:

data:
  mesh: |-
    accessLogFile: /dev/stdout
    defaultConfig:
      discoveryAddress: istiod.istio-system.svc:15012
      proxyMetadata: {}
      tracing:
        zipkin:
          address: zipkin.istio-system:9411
      terminationDrainDuration: 40s

More info about customizing injection here.

Make sure you move all your clients before sinking the ship. Photo: Leonardo.ai

Dancing is about coordination

Kubernetes can’t assure us the order in which it sends the SIGTERM to each one of the containers inside a pod, so we must play the music. We do this by also setting a preStop lifecycle hook to the sidecar, so both the database and the sidecar start counting at the exact same time.

Note: The containers in the Pod receive the TERM signal at different times and in an arbitrary order. If the order of shutdowns matters, consider using a preStop hook to synchronize. Source: Kubernetes docs.

As we already have a preStop in the database, we have left to add it to the sidecar by adding a new container field in the database deployment like this:

spec:
  containers:
  - name: mydatabase
    image: database-image
  - name: istio-proxy # New lines start here
    image: auto
    lifecycle:
      preStop:
        exec:
          command: ["kill", "-SIGTERM", "1"]

This is sending the SIGTERM signal to the sidecar at the exact same time as the 40 seconds counter in the database starts on, making sure the edge cases are covered.

Once the termination grace period is done, any living process in the pod is killed. From Kubernetes 1.27 onward, the termination status will be Failed if some process had to go the hard way.

Are you curious about if a pod in Terminating state is still present it the service’s endpoint ? Check this interesting story about a little test I did.
